7,100 LPH Tetra Pak Tetra Alex 25 (160 Bar) High Pressure Homogeniser (Year 2007)
Request more information
25+ Years in business since 1999
100+ Countries supplied worldwide delivery
Detailed Photos and video see exactly what you're buying
Export Documentation full export sales invoicing customs
100% Servicing and upgrade options available
Expert After-sales support we're here to help after delivery
Description
This is a pre-owned Tetra Pak Tetra Alex 25 Homogeniser, with a capacity of around 7,100 LPH and capable of operating under a maximum pressure of 160 Bar (2,320 PSI). The Tetra Pak Tetra Alex 25 High Pressure Homogeniser is equipped with a horizontally arranged positive displacement pump that includes 3 pistons. This particular model is engineered for the high-pressure homogenisation of emulsions and suspensions, suitable for products such as Pasteurised Milk, UHT Milk, Dairy Cream, Yogurt, Condensed Milk, Ice Cream Mix, Fruit Juices, Concentrates, and more. Currently available in stock, this Tetra Pak Tetra Alex 25 High Pressure Homogeniser is prepared for immediate sale. Please note that ‘Technical Doc’ attachment shown is for information purpose only and the actual equipment under offer might vary in specification.
Specification
- Make: Tetra Pak, Sweden
- Machine Type: Tetra Alex 25
- Model: High Pressure Piston Homogeniser
- Serial Number: T5856827184
- Year of Manufacture: 2007
- Working Capacity: Approx 7,100 LPH
- Working Pressure: 160 Bar (2,320 PSI)
- Number of Pistons: 3-Pistons
- Piston Diameter: 56mm
- Piston Material: Chromium Plated Pistons
- Motor Power: 45kw, 400V, 3-Ph & 50H
- Finish: Stainless Steel Shroud
- Not Included: Control Panel
Dimensions
- Length: 2240mm
- Width: 1400mm
- Height: 930mm
