Miromatic Mirodos MRA-T1-70K Mixing Station

Description

The MiroDos is a unit that can be used for the mixing of low to viscous products, such as Milk, Cultures, Yoghurt, Quark, Fruit, Processed Cheese, etc.

Features

• Manufacturer: Miromatic
• Model: Mirodos P 416/MRA-T1-70K
• Function: Mixing Station
• Fitted with rotary seals with sterile channels
• Frequency Controlled Drive Shaft
• Build: 2004

Technical Specifications: Dairy

• Capacity: 500 kg – 3.000 kg/h Finished Product
• Operating Pressure: Max 10bar
• Programming: Up to 50 Product Recipes
• Cleaning: CIP
• Cleaning Temperatures: 85° C
• Liquid & Steam Sterilisation: Steam max. 120° C. approx. 25 Min
• Electricity: 4 kW
• Air Pressure: 7 bar
• Control Panel: Siemens S7
• Single Dosing Station: 500 - 3.000 kg/h
• Build: Stainless Steel

Technical Specifications: Viscous Products

• Operating Pressure: Max. 4bar
• Capacity: 1.200 kg – 3.000 kg/h Finished Product
• Programming: up to 50 Product Recipes
• Single Dosing Station: 1.200 - 3.000 kg/h

Dimensions

• Length:155 cms
• Width:110 cms
• Height:140 cms
• Weight: 1300 kgs

Country of Manufacture

Germany
