Description
Technogel Mixtronic pasteurisers are compact computer controlled machines designed to regulate both high temperatures pasteurisation at +85ºC and the low temperature pasteurisation at +65ºC.
The built in emulsifier gives the option of automatic or manual operation and guarantees perfect mixing of the ingredients and homogenous distribution of the emulsifiers.
Features
- Manufacturer: Technogel
- Model: Mixtronic 110
- Function: Ice cream batch pasteuriser
- Serial number: 00316/02C
- Load capacity per cycle:40 – 110 litres
- Cycle/process time: 2 hours
- Refrigerating gas: R404A
- Year of manufacture: 2008
- Total power:11 kW
- Compressor power: 2.9 kW
- Electrics: 400V / 50 hz / 3 Phase
- Water cooled
- Instruction manual included
- See technical document attached for further details
Dimensions
- Length:90 cms
- Width:52 cms
- Height:108 cms
- Weight:370 kgs
Country of Manufacture
Italy
Download Technical Doc
