Available for immediate sale is this Sordi Automatic CIP (Cleaning In Place) System, manufactured in 2022 and offered in never installed, never used condition. Designed and manufactured by Sordi, this fully automatic CIP cleaning plant provides reliable, efficient and hygienic cleaning of complete dairy, food and beverage processing installations. The system has been engineered to automatically clean processing equipment, pipelines, tanks, pasteurisers, heat exchangers, homogenisers and filling lines whilst minimising water, chemical and energy consumption.
The plant is configured with three 2,000 litre stainless steel tanks, consisting of a Recovery Water Tank, Acid Dilution Tank and Caustic (Lye) Dilution Tank, together with two independent cleaning channels allowing simultaneous cleaning of separate production circuits for increased operational efficiency. This Sordi CIP System incorporates hygienic stainless steel centrifugal circulation pumps, in-line sanitary filters, tubular heat exchangers, automatic modulation valves, automatic process valves, dosing system, and a comprehensive package of process instrumentation. The complete system is controlled from a stainless steel PLC control panel with touchscreen HMI, providing fully automatic cleaning programmes with repeatable and consistent cleaning performance.
Designed for continuous industrial operation, the plant offers a complete turnkey cleaning solution for dairy and food processing facilities requiring high standards of hygiene and process reliability. As this unit has never been commissioned, installed or placed into production, it represents an outstanding opportunity to acquire a virtually new automatic CIP system at a substantial saving compared with the cost of a new installation. Please note: Downloadable technical documentation provided below is for guidance only and may not reflect the exact specifications of the plant offered.
Technical Specification
- Manufacturer: Sordi, Italy
- Model: SEC.500
- Year of Manufacture: 2022
- Machine Type: Automatic Cleaning In Place (CIP) System
- Configuration: 3-Tank, 2-Channel
- Capacity/Flowrate:
- Channel 1: Approx 30,000 LPH
- Channel 2: Approx 10,000 LPH
- Tank Capacity: 3 × 2,000 Litres
- Tank Arrangement:
- Recovery Water Tank – 2,000 Ltr Single Skin Stainless Steel Tank
- Acid Dilution Tank – 2,000 Ltr Insulated & Clad Stainless Steel Tank
- Lye Caustic Dilution Tank – 2,000 Ltr Insulated & Clad Stainless Steel Tank
- Cleaning Circuits: 2 off Independent Channels
- Cleaning Pumps: Hygienic Stainless Steel Centrifugal Pumps
- Heating System: Twin Tubular Heat Exchangers
- Heating Control: Automatic Hot Water Modulation Valves
- Filtration: Twin In-line Sanitary Filters
- Chemical Dosing: Disinfectant Dosing Pump
- Valve Control: Automatic Pneumatically Operated Hygienic Valves
- Utilities Required: Compressed Air
- Control System: PLC with Touchscreen HMI
- Construction: Hygienic Stainless Steel, Skid Mounted
- Condition: Never Installed / Never Used
Components Included:
- Pneumatic Actuated Automatic Butterfly Valves with Feedback
- 2x Shell-In-Tube Tubular Heat Exchanger
- Flow Sensors
- Inline Filter on the Delivery Line
- Conductivity & Temperature Probes
- High & Low Level Sensor for Tanks
- Steam Regulating Valve
- Control Panel with PLC and HMI
Country of Manufacture
- Italy
