Description
The Stargel machines are electronic horizontal batch freezers for the production of artisan ice cream. Equipped with an electronic programming board, these machines are entirely operator friendly displaying the programmes selected, function and, if present, problem auto-diagnostic status.
Features
- Manufacturer: Promag
- Model: Stargel 90
- Serial number: IC107575
- Function: Batch freezer
- Min. hourly production (output): 50 litres
- Max. hourly production (output): 100 litres
- Speed mixer motor with indirect gear uni transmission
- Front loading door with double interlock microswitch
- Ice cream programme with 6 selections plus the standard
- Granita slush programme with 4 selections plus the standard
- Ice cream holding programme at cycle end
- Wash programme
- Retracting wash jet head with manual pressure control
- Adjustable height tray rack with large size slip resistant mat
- Front swivel and rear fixed position wheels
- Fully CE complying
- Time per cycle max. capacity ice cream: 10-20 min.
- Power:6.4 kW
- Electrical: 380 – 415 V/ 3 Phase/ 50Hz
- Water cooled
- Refrigerant: R404A (1,100 kg)
Dimensions
- Length: 73 cms
- Width: 50 cms
- Height:140 cms
- Weight:370 kgs
Country of Manufacture
Italy
