Description
The ROKK 4 Series high pressure homogenisers and piston pumps have excellent performance and reliability in the latest design concept.
ROKK 4-Series homogenisers / piston pumps are available with capacities from 1000 – 2000 litres / hour as no stage, one stage or double stage depending on application.
Features
- Manufacturer: ROKK
- Model: 4-Series
- Function: Homogeniser
- Serial number: 18024
- Year of manufacture: 2019
- Capacity: 1200 litres / per hour
- *4-Series capacities available ranging from 1000 – 2000 litres / per hour
- Max. working pressure: 250 bar
- Number of stages: 2-Stage machine
- Valve design: Mushroom
- Piston design: Stainless steel (Ceramic coated)
- Tungsten carbide homogenising valves
- Total installed power:11 kW
- Number of plungers: 3
- Valve arrangement: Mushroomvalve
- Includes gear reducer
- Electrics: 380V / 50 Hz / 3 Phase
- Please see ‘Technical Doc’ link for further details
Dimensions
- Depth:165 cms
- Width:94 cms
- Height:102 cms
- Weight:800 kgs
Download Technical Doc
