Description
A Used Tetra Pak Alex 25 for high-pressure homogenisation of emulsions and suspensions. The product is pumped under high pressure into the homogenising device. In the device the product is forced through a small annular gap where the pressure transform into high velocity. Extreme turbulence and cavitation effectively reduce the size of liquid droplets and solid particles.
Features
- Manufacturer: Tetra Pak
- Model: TAM 25
- Serial Number:T5845520043
- Function: Homogeniser
- Capacity: 3.000litres/per hour
- Year of manufacture: 2000
- Max. working pressure: 400 bar
- Total installed power:45 kW (1480 r/min)
- Number of stages: 2-Stage machine
- Valve design: Mushroom
- Piston diameter: 36mm
- Piston design: Chromium plated
- Piston packing: V-packing
- Electrics: 380 V / 50 Hz / 3 Phase
- Finish: Stainless steel covers
- Instruction manual included
Dimensions
- Length: 230 cms
- Width: 145 cms
- Height: 115 cms
- Weight: 1880 kgs
Country of Manufacture
Sweden
