Description
The Cattabriga P1 is a 1 Flavor + Mix, Pump Counter Top, Single Phase Soft ServeMachine. Thanks to it’s Peristaltic Pump (Pantented) and refrigerated cabinet the flushing can be done 2 times a week, assisted by the defrost system, the cleaning has to be performed once a month. The Flushing* lasts around 15-20 minuteswhile the duration of the complete cleaning cyclewill takearound 30 minutes.Apart from the shorter flushing and cleaningcycleis the incredible simplicity ofthe machine. The machine is Dialog Ready. The Revolutionary automatic air inlet allow the customer to control from the screen the Overrun from 15-20% up to 80-90% (Patented). The machine does not waste any space around it thanks to the Air Inlet located under the machine and the outlet on the top of it. The machine is available in standard version in the colors white and black, but can be Tailored for your shop for minimum order of 5machines. The productivity is 24 litres per hour and the “Count Down System” allows the User to keep producing soft serve one after the other without standing in front of the machine waiting the machine can make 1 cone every 12”. Optional: a nice simple short portioning pipe can be easily applied for your cold pastry creations.
Unique Technologies
Bag-in-box: Feeding system by a bag of mix connected into the unit.
Direct expansion cylinder: Patented, makes the gas impact over the several parts of the cylinder as homogeneous as possible.
Automatic fan control: Fan speed varies according to the actual needs of the machine, reducing noise level.
Dialog system: Remote assistance and monitoring system.
TC board: In-house software, with high free memory slots for the remote updates.
Double and independent motor: Improves the production and allows to adjust freezing power independently on each side.
Plug & play: It allows to plug the machine into a single-phase installation, without losing any efficiency or performance.
Peristaltic pump: User-friendly and easy to maintain, while highly performing.
Features
| Hourly production | 24litres |
| Flavours | 1 |
| Capacity tank | 5 litres |
| Installed power | 1,8 kW |
| Cooling | Air |
| Electrical supply | 230 / 1 / 50 Hz |
| Width | 300mm |
| Depth | 780 mm |
| Height | 925 mm |
| Weight | 97kg |
Country of Manufacture
Italy
