Description
The SE85X is a self-cleaning centrifugal separator for milk and whey. Fully serviced – list of works available upon request.
Features
- Manufacturer: Seital (SPX)
- Model: SE85X-Q3P3
- Function: Milk & whey separator
- Year of manufacture: 2018
- Serial number: M02849
- Milk skimming capacity: 45.000 l/h
- Whey skimming capacity: 52.000 l/h
- Milk standardization and cleaning capacity: 52.000 l/h
- Solids chamber capacity: 17.0 litre
- Bowl speed: 4.800 rpm
- Optimal milk skimming range temperature: 45-55 °C
- Optimal whey skimming range temperature: 30-40°C
- Operating inlet pressure: 0.5 – 1.5 bar
- Maximum useful skim pressure: 3,0 bar
- Maximum useful cream pressure: 2,5 bar
- Total installed power: 45 kW
- Complete with tools, base plate and control panel
- Instruction manual supplied
- See ‘Technical Doc’ link for further details
Dimensions (on skid)
- Length: 212 cms
- Width: 257 cms
- Weight: 3900 kgs
Country of Manufacture
Italy
Download Technical Doc
