Description
The Ecogel 40-120 vertical batch freezer from Telme. Enhanced performance. Greater savings. The patented “DSRS” (Dual Stage Refrigeration System) reduces the nominal power used by 20%. It can operate one or both of the compressors. Therefore, mixing and freezing for extraordinarily fast production is possible, or energy saving of more than 40%. Gelato processing is always optimal both with a reduced load and with the maximum load of mix.
Features
- Manufacturer: Telme
- Model: Ecogel 40-120 W
- Function: Vertical ice cream batch freezer
- Year of manufacture: 2011
- Serial number: 04 / 170
- Load capacity per batch:5-18litres
- Cycle/process time:6-12minutes
- Outlet capacity (per hour): Approx. 120 Litres
- Water cooled
- Electrics: 400V / 50 Hz / 3 Phase
- Total installed power:12 kW
- Refrigerant: R404A (2500 grams)
- See ‘Technical Doc’ link for further details
Dimensions
- Length:78 cms
- Width:55 cms
- Height:120 cms
- Weight:350 kgs
Country of Manufacture
Italy
