Description
The Tetra Pak® Cheese Vat OST CH6 is a horizontal vat for the curd production of cheddar/mozzarella cheese types. The vat has all required functions for a controlled and predictable process: filling of cheese milk, ingredient mixing, milk coagulation, cutting of coagulum, blending, indirect heating, emptying and CIP (Cleaning in Place). The Tetra Pak Cheese Vat OST CH6 is designed to satisfy the cleaning requirements after each batch especially for cheddar, mozzarella and similar cheese types. Using warm water in a dimple jacket to heat the product allows the operator to control the heating speed and temperature difference. In the recipe the maximum temperature difference between heating medium and product can be set, so the optimal heating rate will be achieved.
Features
- Manufacturer: Tetra Pak
- Model: OST CH6
- Function: Horizontal vat for curd making
- Serial number: 5847170045-5847170046
- Capacity: 30.000 Litres
- Year of manufacture: 2019
- Orientation: Horizontal
- Construction: 304 grade stainless steel
- Shape: Cylindrical
- Total installed power: 7.5 kW
- Includes PLC stainless steel control panel
- Documentation available
- See ‘Technical Doc’ link for Tetra Pak brochure
Dimensions
- Length: 759 cms
- Width: 330 cms
- Height: 350 cms
- Net weight: 6000 kgs
Download Technical Doc
