APV Rannie 15-30.56 Homogeniser, 600 l/h

Description

A Used Rannie 15-30.56 Homogeniser from APV / SPX for high-pressure homogenisation of emulsions and suspensions. The product is pumped under high pressure into the homogenising device. In the device the product is forced through a small annular gap where the pressure transform into high velocity. Extreme turbulence and cavitation effectively reduce the size of liquid droplets and solid particles.

Features

• Manufacturer: APV Rannie
• Model:15-30.56
• Function: Homogeniser
• Capacity: 600 litres/per hour
• Serial number: 1-01.181
• Yearof manufacture: 2001
• Max. working pressure:300 bar
• Motor power:7.5 kW
• Piston diameter: 30 mm
• Piston stroke:56 mm
• Number of stages: 2-Stage machine
• Stainless steel cladded
• Instruction manuals included
• Electrics: 380V / 3Phase / 50hz
• See ‘Technical Doc’ link for further details

Dimensions

• Depth: 175cms
• Width:105 cms
• Height:200 cms
• Weight:1400Kgs

Country of Manufacture

Denmark
